CtS Exposure

STM-ONE

Compact CtS system for small to medium stencil volumes with an attractive entry price.







1 / 7

Description

Max. screen format (H x W): 1200 x 1200 mm (S) / 1250 x 1500 mm (M)
Max. exposure format (H x W): 1000 x 1040 mm (S), 1150 x 1340 mm (M)
MODULAR CtS CONCEPT / Generation 4 Technology
Attractive price for small and medium screens volumes
Multiple image production: several smaller screens can be simultaneously exposed
Compact and space saving construction thanks to the front loader design
High-quality exposure head with a guaranteed resolution of 1270, 1609, 2400 or 3040 dpi
UV light sources based on the MODULAR CtS CONCEPT: LED_Q4, CPL lamp or LED DUO guarantee perfect exposure for almost all fabrics and emulsions.
One hundred percent precision for the image positioning on the screen, thanks to laser recording
Rugged and high-quality construction
